Scrap Metal baler

Description

Scrap Metal Balers, also called hydraulic metal baler, are widely applicable in many metallic fields, including steel plants, recycling companies, smelting industry. This type of baler is designed to press metal scraps into furnace charges (cuboids, cylinder or octagon). The scraps includes scrap steel, scrap copper, scrap aluminum, scraps stainless steel, discarded automobiles, metal sheet, steels scrap iron. Hence, the baler can reduce transportation cost and speed up furnace charging.

Features

1. Motivated by hydraulic pressure, the balers operates smoothly and safely.
2. The balers adopt manual or PCL automatic model.
3. Three types of feeding are available. They are turn-out, push-out and forward-out.
4. The balers are installed without the foundation bolt. It can be powered by diesel fuel when there is no electricity available.

Advantages

1. High Efficiency
The balers operate at high speed without consuming much energy. In this case, the efficiency of the hydro press is greatly improved, and the production cost is saved.
2. Advanced Mechanical and Electrical System
With the advanced technology in machinery and electronics, the entire hydraulic system becomes more complete.
3. Full Automatic Model
The rapid development of micro-electronic technology gives full play to the automation and intelligentization of the hydro press. The processing process is automated. Besides this, the hydro press can detect and adjust the system automatically, and preprocess the faults.
4. Hydraulic Integration and Standardization
The integrated hydraulic system reduces tube connection, which efficiently prevent leakage and pollution. And the standardized components make it convenient to repair and maintain.

Types

Y81Q-1350, Y81T-2500

Specifications

No.		Specifications
Model				Y81Q-1350
1	Main Cylinder		Type	YG250/160
			Pressure	1350 KN
			Stroke	1720 mm
			Qty.	1 pc
2	Plate Cylinder		Type	YG160/105
			Pressure	530 KN
			Stroke	1160 mm
			Qty.	1 pc
3	Bales Out Door Cylinder		Type	YG110/70
			Pressure	250 KN
			Stroke	260 mm
			Qty.	2pcs
4	Ejecting Cylinder		Type	N/A
			Pressure	N/A
			Stroke	N/A
			Qty.	N/A
5	Chamber Size			1400×600×600 mm
6	Bales Size (L×W×H;H is adjustable)			600×240×H mm
7	Hydraulic Pressure			25 MPa
8	Cycle Time			~70 s
9	Motor		Type	Y200L2-6
			Rated Power	22 KW
			Rated Speed	970 rpm
			Qty.	1 pc
10	Pump		Type	160YCY14-1B
			Flow Rate	160 ml/r
			Rated Pressure	31.5 MPa
			Qty.	1 pc
11	Machine Weight			6 ton
